Selected:

MJ-PC-DF-LCA/LCA-SM-3M

$10.00

PRODUCTS

  • XFP 10G Transceivers

    XFP 10G Transceivers (17)

    The XFP MILJET Modules are products with the best components on the market, have certifications and are homologated by the largest Telecommunications Players in the World. Transceivers SFP + are for Capacity up to 10Gbps and can reach from 300m to 120km. We have several Application Models SR, LR, ER, ZR, LRM, DWDM, CWDM, LW, SW in Lengths from 850nm…
  • SFP+ 10G Transceivers

    SFP+ 10G Transceivers (21)

    The SFP+ MILJET Modules are products with the best components on the market, have certifications and are homologated by the largest Telecommunications Players in the World. Transceivers SFP+ are for Capacity up to 10Gbps and can reach from 300m to 100km. We have several Application Models SR, LR, ER, ZR, LRM, DWDM, CWDM, LW, SW in Lengths from 850nm up…
  • SFP 1.25G Transceivers

    SFP 1.25G Transceivers (20)

    The 1.25G SFP transceivers is a small, compact, self-connecting transceiver used for telecommunication and data communications applications. SFP modules are designed to support SONET, Gigabit Ethernet, Fiber Channel and other communication standards. Most SFP transceivers are used for Gigabit Ethernet. SFP if the next generation of GBIC and about half the size of the GBIC. All SFP tansceiver can come…
  • QSFP28 100G Transceivers

    QSFP28 100G Transceivers (3)

    The 100G QSFP28 transceiver module is a high-density, high-speed product designed for 100Gbps applications. It has the same form factor as the QSFP+ transceivers. QSFP28 100G optics offers four channels of high-speed differential signals with data rates ranging from 25 Gbps up to potentially 40 Gbps, and finally meet 100 Gbps Ethernet (4×25 Gbps) and 100 Gbps 4X InfiniBand Enhanced…
  • QSFP+ 40G Transceivers

    QSFP+ 40G Transceivers (6)

    QSFP is short for quad (4-channel) small form-factor pluggable. It is a compact, hot-pluggable transceiver also used for data communications applications. QSFP+ evolved as the standard to support 10Gb/s data rates per SFF-8436. Compared with QSFP+, QSFP products support Quarter Small Form-factor Pluggable with the different data rate so that there is no change in the product solution. Nowadays, QSFP+…
  • MTP/MPO Fiber Optic Cables

    MTP/MPO Fiber Optic Cables (8)

    We supply MTP and MPO fiber optic cables. These are available in Female to female or a male to male and male to female configurations. The male version has MTP pins. These can be made with 12 fiber MTP connectors, 24 Fiber MTP connectors, 48 Fiber MTP connector variations. We use USConec MTP fiber optic connectors for all of our…
  • Fiber Optic Patch Cords

    Fiber Optic Patch Cords (20)

    Fiber optic patch cords are short distance fiber capped with connectors at both ends for easy installation at patch panels, optical switches, and telco equipment. We are a leading supplier of fiber optic patch cords including: single mode and multimode OM1, OM2, OM3 and OM4 These are available outfitted with LC, SC, or ST connectors in PC, UPC, and APC…
  • DAC & AOC Cables (23)

    DAC cable and AOC cable are widely applied in storage area network, data center, and high-performance computing connectivity, etc. AOC vs. DAC: The correct choice can be made when you are clear about the advantages and disadvantages of each. MILJET provides various kinds of high speed interconnect DAC assemblies including 10G SFP+ Cables, 40G QSFP+, 100G QSFP28 Cables. DAC or…

MJ-PC-DF-LCA/LCA-SM-3M

The duplex fiber optic cable consists of two strands of glass usually in a thin web construction that can be separated. It is commonly used for fiber applications where a separate transmit and receive are necessary. When simultaneous bidirectional data transfer is required, then you’ll require duplex fiber cable. The Duplex Fiber Optic Cable, Zip Cord, Single Mode, 9/125 is manufactured of genuine Corning glass with a plenum rated construction. This duplex fiber optic cable is made with a tight buffer, an aramid yarn and a PVC outer jacket. All materials of its construction meet the RoHS and REACH Directive standards. This duplex fiber cable is UL listed OFNP for safe usage inside environmental air handling spaces like plenums. Insertion loss ≤0.3dB and Return loss ≥60dB, Fiber Grade Bend Insensitive, Minimum Bend Radius 10 mm.



Product Details:

Patch Cord LC/APC-LC/APC SM 9/125 Duplex Fiber 3M, 2.0mm PVC

Vendor Name:
MILJET SOLUTIONS, INC.
Part Number:
MJ-PC-DF-LCA/LCA-SM-3M
Wavelength:
1550nm 0,22dBm/km <> 1310nm 0,36dBm/km
Data Rate:
10G/40G
Formfactor Name:
APC to APC
Max Distance:
3m (10ft)
Optical Monitor DOM:
NA
Cable Type:
Duplex PVC 2.0mm
Optical Components:
Blue & Yellow Flame Retardant PVC
Connector:
SC to SC
Receiver Sensitivity:
(0.2/0.4) dB/km
TX Power:
NA
Protocols:
G.657.A1, RoHS, MSA Compliant
Temperature Range:
0°C to +70°C | -40°C to +70°C
Model Type:
OS2 9/125μm SMF
Download Datasheet:
teste
Click Here
